| 1 |
028120018000
|
CARBURETTOR, 390CC
|
390cc |
€
803.78
|
|
|
| 1 |
030120018000
|
CARBURETTOR, 480CC
|
480cc 480 RACING |
€
803.78
|
|
|
| 1 |
029120018000
|
CARBURETTOR, 430CC
|
430cc 430 RACING |
€
808.34
|
|
|
| 2 |
006120210000
|
PLUG
|
430 RACING 480 RA... |
€
5.18
|
|
|
| 5 |
3625146000
|
Carburetor Cover
|
|
€
22.56
|
|
|
| 12 |
3625155000
|
Throttle Shaft Cpl
|
|
€
98.78
|
|
|
| 14 |
3625156000
|
Throttle Shaft Spring
|
|
€
0.00
|
|
|
| 16 |
3625150000
|
Link Arm Throttle Valve Cpl
|
|
€
60.16
|
|
|
| 18 |
3625241000
|
Slide Stop
|
|
€
19.98
|
|
|
| 19 |
3625149000
|
Throttle Valve Cpl
|
|
€
402.85
|
|
|
| 20 |
3625249000
|
Bushing Throttle Valve
|
|
€
7.25
|
|
|
| 21 |
3625151000
|
Gasket, Throttle Valve Plate
|
|
€
152.67
|
|
|
| 22 |
3625250000
|
Washer, Throttle Valve Plate
|
|
€
12.31
|
|
|
| 23 |
006120010000
|
JET NEEDLE OBDTS KEIHIN
|
|
€
17.50
|
|
|
| 24 |
006120130000
|
JET NEEDLE KEIHIN NCVQ
|
|
€
15.88
|
|
|
| 25 |
3625240000
|
Bar Clip
|
|
€
4.40
|
|
|
| 26 |
3625147000
|
Needle Set Screw Cpl.
|
|
€
31.30
|
|
|
| 27 |
3625256000
|
Needle Jet Fcr-Mx
|
|
€
23.21
|
|
|
| 28 |
3625107000
|
Main Jet 162 Keihin
|
162 |
€
9.35
|
|
|
| 30 |
1642355000
|
Starter jet 38
|
38 |
€
17.02
|
|
|
| 31 |
3625253000
|
Starter Jet 85 Keihin
|
85 |
€
12.93
|
|
|
| 32 |
3625139000
|
Idle Air Jet 100 Keihin
|
100 |
€
12.27
|
|
|
| 33 |
3625237000
|
Adjust Screw Cpl. Fcr-Mx
|
|
€
12.73
|
|
|
| 34 |
3625166000
|
Buffer Plate
|
|
€
8.27
|
|
|
| 35 |
3625141000
|
Float Cpl
|
|
€
42.20
|
|
|
| 36 |
3625140000
|
Arm Pin Float
|
|
€
1.89
|
|
|
| 37 |
006120080000
|
FLOAT NEEDLE VALVE
|
|
€
22.40
|
|
|
| 38 |
006120090000
|
CLAMP FLOAT NEEDLE VALVE
|
|
€
3.68
|
|
|
| 39 |
3625170000
|
Drain Screw Float Chamber
|
|
€
4.89
|
|
|
| 40 |
3625161000
|
Cover Accelerator Pump
|
|
€
17.37
|
|
|
| 41 |
3625142000
|
Float Chamber
|
|
€
169.51
|
|
|
| 42 |
006120020000
|
LEAK JET, 40 KEIHIN
|
40 |
€
4.31
|
|
|
| 43 |
3625254000
|
Coil Spring
|
|
€
5.07
|
|
|
| 44 |
3625157000
|
Starter Valve Cpl.
|
|
€
65.26
|
|
|
| 45 |
3625168000
|
Breath Hose Fcr-Mx Keihin Cpl.
|
|
€
88.38
|
|
|
| 46 |
3625154000
|
Screw F. Cover
|
|
€
7.03
|
|
|
| 47 |
3625143000
|
Holding Bolt
|
|
€
12.13
|
|
|
| 48 |
3625163000
|
Intermediate Lever Cpl
|
|
€
20.57
|
|
|
| 49 |
3625159000
|
Link Lever
|
|
€
4.63
|
|
|
| 50 |
006120040000
|
AC SPRING, "GREEN" KEIHIN
|
|
€
5.25
|
|
|
| 51 |
3625171000
|
Spring Intermediate Lever
|
|
€
5.98
|
|
|
| 52 |
3625153000
|
Carburetor Cover
|
|
€
18.46
|
|
|
| 53 |
3625167000
|
Washer Link Lever Carbura- tore Keihin
|
|
€
1.40
|
|
|
| 54 |
3625165000
|
E-Clip
|
|
€
2.14
|
|
|
| 55 |
3625162000
|
Rod Accelerator Pump
|
|
€
18.11
|
|
|
| 56 |
1067470000
|
Pipeclampingring
|
|
€
1.53
|
|
|
| 57 |
006120850000
|
INTAKE MANIFORD
|
|
€
24.15
|
|
|
| 58 |
006120900000
|
ENGINE VENTILATION HOSE RR4T MY'10
|
|
€
7.28
|
|
|
| 59 |
3625145000
|
Stop Screw Cpl Fcr-Mx
|
|
€
44.76
|
|
|
| 60 |
3625255000
|
Throttle Position Sensor
|
|
€
209.73
|
|
|
| 61 |
029120000000
|
INTAKE MAINFOLD RR4T
|
|
€
15.04
|
|
|
| 62 |
1514607800
|
Carburetorclamp d.58 with screw+ spacer
|
|
€
4.92
|
|
|
| 63 |
3625169000
|
Gasket Set Fcr-Mx
|
|
€
63.14
|
|
|
| 231 |
3625239000
|
JET OBDVT NEEDLE KEIHIN
|
|
€
19.94
|
|
|
| 232 |
3625248000
|
Jet Needle Obdtr Keihin
|
|
€
19.94
|
|
|
| 233 |
3625242000
|
JET OBDVR NEEDLE KEIHIN
|
|
€
19.27
|
|
|
| 234 |
3625491000
|
JET NEEDLE KEIHIN OBDVS
|
|
€
22.56
|
|
|
| 235 |
3625148000
|
Jet Needle Keihin Obekt
|
|
€
20.83
|
|
|
| 236 |
3625244000
|
Jet Needle Keihin Obetn
|
|
€
25.00
|
|
|
| 237 |
3625245000
|
JET NEEDLE KEIHIN OBETQ
|
|
€
17.98
|
|
|
| 238 |
006120110000
|
JET NEEDLE KEIHIN OBETR
|
|
€
15.88
|
|
|
| 239 |
006120120000
|
JET NEEDLE KEIHIN OBETS
|
|
€
15.88
|
|
|
| 241 |
006120140000
|
JET NEEDLE KEIHIN NCVR
|
|
€
15.88
|
|
|
| 242 |
006120150000
|
JET NEEDLE KEIHIN NCVS
|
|
€
15.88
|
|
|
| 243 |
3625420000
|
Jet Needle Obdvr Keihin
|
|
€
19.94
|
|
|
| 281 |
3625108000
|
Main Jet 165 Keihin
|
165 |
€
9.35
|
|
|
| 282 |
3625109000
|
Main Jet 168 Keihin
|
168 |
€
9.63
|
|
|
| 283 |
3625110000
|
Main Jet 170 Keihin
|
170 |
€
9.92
|
|
|
| 284 |
3625111000
|
Main Jet 172 Keihin
|
172 |
€
9.32
|
|
|
| 285 |
3625112000
|
Main Jet 175 Keihin
|
175 |
€
9.42
|
|
|
| 286 |
3625113000
|
Main Jet 178 Keihin
|
178 |
€
9.06
|
|
|
| 287 |
3625114000
|
Main Jet 180 Keihin
|
180 |
€
9.14
|
|
|
| 288 |
3625115000
|
Main Jet 182 Keihin
|
182 |
€
9.14
|
|
|
| 289 |
3625116000
|
Main Jet 185 Keihin
|
185 |
€
9.06
|
|
|
| 290 |
3625117000
|
Main Jet 188 Keihin
|
188 |
€
9.06
|
|
|
| 291 |
3625118000
|
Main Jet 190 Keihin
|
190 |
€
9.06
|
|
|
| 301 |
3625101000
|
Idle Jet 40 Keihin
|
40 |
€
8.51
|
|
|
| 302 |
1642347000
|
Slow jet 42
|
42 |
€
7.02
|
|
|
| 303 |
1642349000
|
Slow jet 45
|
45 |
€
6.45
|
|
|
| 304 |
1642348000
|
Slow jet 48
|
48 |
€
6.60
|
|
|
| 421 |
006120030000
|
LEAK JET, 50 KEIHIN
|
50 |
€
5.50
|
|
|
| 422 |
006120230000
|
LEAK JET, 60 KEIHIN
|
60 |
€
4.31
|
|
|
| 423 |
006120070000
|
LEAK JET, "0" KEIHIN
|
CLOSED |
€
3.79
|
|
|
