| 1 |
3625258000
|
Outer Clutch
|
€
212.60
|
|
|
| 2 |
3625485000
|
Inner Hub(2007/2008 Version 400 - 450 - 525 cc)
|
€
85.70
|
|
|
| 3 |
02902052000
|
Lining Disc 2mm
|
€
16.57
|
|
|
| 4 |
02903050 000
|
Intermediate Disc 1mm
|
€
4.30
|
|
|
| 5 |
3625486000
|
Pressure cap with oil bore(2007/2008 Version 400 - 450 - 525 cc)
|
€
48.71
|
|
|
| 6 |
3625262000
|
Clutch Spring 2,5x43mm
|
€
2.64
|
|
|
| 7 |
3625263000
|
Spring Retainer 6,2x12x18x3,6mm
|
€
0.00
|
|
|
| 10 |
3625269000
|
Push Rod 7x188mm
|
€
10.51
|
|
|
| 11 |
3625264000
|
Push Rod 7x188mm
|
€
2.38
|
|
|
| 12 |
3625268000
|
Supportwasher 25x35x1
|
€
0.00
|
|
|
| 13 |
3625073000
|
Ah Screw M6 X 25
|
€
1.27
|
|
|
| 14 |
3625029000
|
Needle Bear K 25x29x10
|
€
4.49
|
|
|
| 15 |
3625257000
|
Primary Gear 33 T
|
€
83.50
|
|
|
| 16 |
1291895033
|
Output Cylinder Cpl.
|
€
146.65
|
|
|
| 17 |
3625058000
|
O-Ring 30,00x1,50 Nbr 70
|
€
0.00
|
|
|
| 18 |
3625090000
|
Vent Injektion Hydr. Clutch
|
€
56.59
|
|
|
| 19 |
3625272000
|
Piston With O-Ring And Ball
|
€
0.00
|
|
|
| 20 |
3183530000
|
Magura Hydraulic Pump Special Screw
|
€
24.00
|
|
|
| 21 |
3625009000
|
Bolt 6.35
|
€
1.27
|
|
|
| 22 |
1149070000
|
Bolt 6.20
|
€
1.03
|
|
|
| 23 |
3625265000
|
Stepped Washer
|
€
4.35
|
|
|
| 24 |
3625271000
|
Gasket For Slave Cylinder
|
€
2.19
|
|
|
| 26 |
3625261000
|
Driving Sleeve D=8, L=31
|
€
1.82
|
|
|
| 27 |
3625079000
|
Circlip Rw12
|
€
0.14
|
|
|
| 28 |
3625131000
|
Axial Washer 12x26x1
|
€
1.73
|
|
|
| 29 |
3625130000
|
Axial Needle Bearing
|
€
5.87
|
|
|
| 30 |
3625092000
|
Pressure Piece
|
€
13.72
|
|
|
| 31 |
3625069000
|
Hexagon Nut M18x1,5
|
€
3.30
|
|
|
| 32 |
3625137000
|
Lock Washer
|
€
3.52
|
|
|
| 33 |
3625270000
|
Hollow Screw Hydr. Clutch Cpl.
|
€
0.00
|
|
|
