| 1 |
3625210000
|
Engine Case Cpl. W.Tr.Bear
|
€
0.00
|
|
|
| 2 |
3625099000
|
Dowel 17 X 14 X 12
|
€
3.85
|
|
|
| 3 |
3625087000
|
Dowel 9,8 X 7 X 10
|
€
2.46
|
|
|
| 4 |
3625235000
|
Hanger For Vent Hose
|
€
2.50
|
|
|
| 5 |
3625004000
|
Hh Collar Screw M 6x15
|
€
0.55
|
|
|
| 6 |
3625176000
|
Oildrain Plug W.Mag M 12 X 1,5
|
€
7.42
|
|
|
| 7 |
3625187000
|
Cu-Seal Ring Din 7603 - 12 X 18 X 1,5
|
€
1.41
|
|
|
| 9 |
3625062000
|
Plug - M12 X 1,5
|
€
3.47
|
|
|
| 10 |
3625221000
|
Dowel 17 X 19 X 12
|
€
3.96
|
|
|
| 11 |
3625189000
|
Pressure Spring L=25mm D=1mm
|
€
3.01
|
|
|
| 12 |
3625190000
|
Valve Piston D=10mm
|
€
0.00
|
|
|
| 17 |
3625252000
|
Engine Breather Tube
|
€
0.00
|
|
|
| 18 |
3625219000
|
Bleeder Flange M12x1,5
|
€
6.72
|
|
|
| 19 |
3625177000
|
Locating Screw M8 L=23 (400-450-525cc)
|
€
5.23
|
|
|
| 20 |
3625178000
|
Cu-Seal Ring 8 X 14 X 3
|
€
1.76
|
|
|
| 21 |
3625019000
|
Needle Roller 2,5 X 9,8
|
€
2.43
|
|
|
| 22 |
3625218000
|
Oil Level Glass G 1777 Y
|
€
0.00
|
|
|
| 23 |
2909602000
|
Oil filter plug(2007/2008 Version 400 - 450 - 525 cc)
|
€
4.04
|
|
|
| 24 |
3625054000
|
O-Ring 19 X 3
|
€
0.17
|
|
|
| 26 |
3625021000
|
Needle Roller 4,0 X 9,8
|
€
0.51
|
|
|
| 29 |
3625015000
|
Washer
|
€
0.28
|
|
|
| 30 |
3625076000
|
Screw M5 X 8
|
€
0.00
|
|
|
| 31 |
3625007000
|
Screw M6 X 8
|
€
0.49
|
|
|
| 33 |
3625212000
|
Ret. Bracket F Brake Lever Hub
|
€
4.31
|
|
|
| 34 |
3625052000
|
O-Ring 12 X 2
|
€
0.36
|
|
|
| 35 |
3625354000
|
Plug, M16 X 1,5
|
€
9.52
|
|
|
| 36 |
3625355000
|
Oil Screen 11,8 X 44,5mm
|
€
11.08
|
|
|
| 37 |
3625051000
|
O-Ring 9 X 1,5
|
€
0.93
|
|
|
| 38 |
3625036000
|
Seal Ring 12 X 18 X 3
|
€
1.66
|
|
|
| 40 |
3625471000
|
CLUTCH COVER BETA
|
€
45.40
|
|
|
| 41 |
3625222000
|
Gasket For Clutch Cover
|
€
15.66
|
|
|
| 42 |
3625472000
|
Gasket, Engine Case(2007/2008 Version 400 - 450 - 525 cc)
|
€
25.50
|
|
|
| 43 |
3625470000
|
Clutch cover assy , Beta(2007/2008 Version 400 - 450 - 525 cc)
|
€
112.54
|
|
|
| 44 |
3625230000
|
Chain Dampersheet
|
€
13.64
|
|
|
| 45 |
3625044000
|
Shaft Seal Ring 14x24x6 B
|
€
0.00
|
|
|
| 46 |
3625045000
|
Shaft Seal Ring 19x30x7
|
€
6.07
|
|
|
| 47 |
3625473000
|
SCREW 6X16
|
€
0.72
|
|
|
| 48 |
3625474000
|
GASKET F.OUTER CLUTCH
|
€
3.64
|
|
|
| 50 |
3625011000
|
Bolt 6.45
|
€
1.63
|
|
|
| 51 |
1105485000
|
Bolt 6.60
|
€
1.24
|
|
|
| 52 |
1150300000
|
Bolt 6.30
|
€
0.62
|
|
|
| 53 |
3625009000
|
Bolt 6.35
|
€
1.27
|
|
|
| 54 |
3625013000
|
Bolt 6.75
|
€
1.57
|
|
|
| 60 |
3625236000
|
Gasket Set Cpl
|
€
202.74
|
|
|
